    SEOOW 105°C 600 Volt UL /CSA Portable Cord

    Introduction:
    FEATURES
    ★ UL Listed for indoor and outdoor use
    ★ Excellent flexibility in cold temperatures
    ★ Ozone-sunlight (UV)- and weather-resistant
    ★ Water, oil, moisture, heat, abrasion and cut resistance
    ★ Good tensile strength, elongation and aging characteristics
    ★ Flame retardant per to FT2, VW-1
    ★ Temperature range from -40°C to +105°C

    GET A QUOTE


    Applications



    Type SEOOW UL/CSA is designed for extra hard usage on industrial equipment, heavy tools, battery chargers, portable lights welding leads, marine dockside power, power extensions and mining applications, it is permitted for use as specified by Article 400 and related articles of the 2011 NEC.

    Construction


    Rated Voltage: 600V
    Conductor: Class K stranded bare copper per ASTM B-174
    Insulation: Premium-grade, oil-resistant TPE 105˚C
    Outer Sheath: Black TPE -40˚C to +105˚C
    SEOOW 105°C 600 Volt UL /CSA Portable Cord

    Core Identification

    2 core---Black, White
    3 core---Black, White, Green
    4 core---Black, White, Red, Green
    5 core---Black, White, Red, Orange, Green

    STANDARDS: ASTM B-174, UL Flexible Cord - UL Subject 62, CSA Flexible Cord - C22.2-49
    APPROVALS:  UL

    SIZE RANGE:
    Cable Type No.of Cores Size(mm²)
    SEOOW 2 18~2
    SEOOW 3 18~2
    SEOOW 4 18~2
    SEOOW 5 18~2


    Certifications


    Mainland Cable manufactures a wide range wires and cables, covering UL portable and industrial cords, VDE harmonized rubber cable and PVC cables, power cords, extension cords, cable reels, welding cables, control cables, crane & hoist cables. Mainland Wire & Cable is qualified by ISO9001 and ISO14001, CCC, UL, CSA, MSHA, BS, SAA, TLC, CE, VDE, PSE, KC, JIS, UL-BRAZIL, SASO, etc.,



    Packaging & Shipping

    1. Packing Details:
    1) Packing Lengths: 250ft, 500ft, 1000ft, 5000ft or other lengths are available according to client's request.
    2) Packing Material: plywood drum, wooden drum etc are available.

    2. Shipping Details:
    1) Lead Time: 25-35 working days or negociation.
    2) Transport Modes: Sea, Express(DHL,UPS,FEDEX, TNT) or request.
